Double Wye With Curved 24 Inch Crossing


Built When Ordered

Production Time: 5 days

The AF-O-Y-24-ME125 will be automatically added to our production queue when it is ordered.

PRICE : $1,049.99

Project #2 – Double Wye With Curved Crossing. This includes all fixtures, including the mirrored versions to match.

    • See attached pic in HO scale…this would hook up with the #3 turnout and curved crossing you did for me last summer.
    • Keep the 24” radius from the #3 wye (which you did for me back in 2011) through the curved crossing
    • On the outer rails not going through the crossing, also keep the 24” radius…I will most likely use a smaller radius to make what is in the picture but a there are track arrangements where the 24” radius is needed.
    • Extend the guardrails throughout the entire design so street track can be made….similar to what you did last summer
    • O scale
    • Code 125


  • Add centerlines and mounting holes like previous fixtures
  • Make every other tie before and after the crossing a PC tie
  • Three fixtures will most likely be needed…that’s OK!
